ceramic knife gate valve

ZC'S Ceramic knife gate valves have one piece integral body design to reduce flow resistance.
2. Inlet seat and outlet seat are ceramics materials. Because high hardness and high strength of high pure 99% Al2O3 ceramics, Foyo ceramic knife gate valves have much longer service life than general metal seated knife gate valves in similar conditions.
3. The gates of ceramic knife gate valves are hardened with nitriding treatment, Tungsten carbide T.C. or hard Chrome to improve working performance.
4. Several structures of ceramic knife gate valves are available on customers' requirement.
5. The actuation of FOYO ceramic knife gate valves can be hand wheel, pneumatic cylinder, electric motor and hydraulic actuator, special requirements are available on customer’s requirement
Size:
DN65-DN600
Material:
WCB , IND Ceramic
Availability:
Inquire

PDF Export
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
sharethis sharing button

  • ZCPZ73TC

  • ZC

  • ZCPZTC

Product Description

Product  Application

ZC ceramic knife gate valve is application as an on-off media containing high –hardness grains ,such as cinder water , or for pipelines with both soft grains and corrosive media .its nominal pressure is 1.0 Mpa ,and application temperature≤150℃ 。the sealing surface adopts had seal , and all medium contacting parts are made of structural ceramic withextremely high chemical stability and hardness .Therefor , it has extremely strong resistance to abrasion ,corrosion and erosion .good heat insulation and small thermal expansion . Its feed inlet is fully through without any blocks and it has strong abrasion resistance a good seal ability and a small strating load , with little ash seizure or accumulation .It adopts a high-grace toughened structural ceramic seal ,featuring high mechanical  strength  ,strong abrasion resistance ,a long service life and a compact structure which can be installed at any angle


Model:ZCPZ73TC

Standard:ASME B16.34

Size:2 1/2"-24"

Pressure:150LB

Estimate Delivery:35 days



Material for main Parts

Item

Name

Material

Item

Name

Material

1

Body

WCB

6

Stem

Q235+Hcr

2

Disc

Ind+Ceramic

7

Yoke

Q235

3

Seat

8

8

Nut

10

4

Packing

PTFE

9

Traval Switch

Assemble

5

Packing Gland

WCB


Pneumatic

Assemble


Application Specification

Design & Manuafcture

GB/ T 8691 ,MSS-SP-81

Connection end dimension

Face to face

GB/T 15188.2 ,MSS-SP-81

Flange dimension

Gb/T9113.1 ,MSS-SP-81

Inspect & Test

JB/T 8691

Material

Carbon Steel

GB/T 12229

Stainless Steel

GB/T12230

Mark

GB/T12220

Supply

GB/T12252
