Lidded Knife Gate Valve with Chain wheel

Lidded knife gate valve is suitable for pipe with sewage and water . And it is installed the pipe in height and thin place where is not convenient to operate . The chain wheel operate to easy . This type knife gate valve is 0 leakage and there are two seals . one sealing is seat and the other is packing sealing . Lidded knife gate valve could be lined PU ring and EPDM ring according to medium .
Size:
2"-96"
Material:
WCB CF8 , CF8M ,CF3M ,CF3,SS310S
Operation type :
Handlewheel , bevel gear box , pneumatic actuator ,Electric actuator , Hydraulic actuator ,
Color:
Blue , customized
Availability:
Inquire

PDF Export
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
sharethis sharing button

  • DMZ4L73X-PN10

  • ZC

  • ZCLKVC

Product Description

Lidded  knife gate  valve with Chianwheel   Operated

Model:DMZ4L73X/H 2”-96”

Solid One Piece Cast Body, welded body
Designed & Tested to MSS SP81

Connection :Wafer Type

Operated type: Chainwheel

MATERIALS OF CONSTRUCTION

Body: Carbon steel , Stainless Steel(Solid solution treatment), Special material
Seat: EPDM, NBR, METAL

COMMON APPLICATIONS

• Waste Water and Water
• Mining
• Bulk Conveyancing
• Pulp & Paper
• Food & Beverage
• Chemical
• Fly Ash Handling
• Sewage
