Electric & Hydraulic Knife Gate Valve

ZC's electric & hydraulic knife gate valve own electric actuator and hydraulic actuator according to working environment . The electric actuator and hydraulic actuator could exchange easy . It suitable for slurry , sewage and chemical . The structure is simple , east to install .
Size:
2"-24"
Material:
WCB , CF3, CF8,CF8M ,CF3M , SS310S
Operation type :
Electric & Hydraulic actuator
Availability:
Inquire

PDF Export
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
sharethis sharing button

  • ZCPZ273H/X

  • ZC

  • ZCPZHE

Product Description

Electric & Hydraulic knife gate valve

Model:PZ273F/H 2”-24”
Solid One Piece Cast Body, Replacement Seat ,Uni directional Type
Designed & Tested to MFS

Connection: Flange

Operated type: .380V , 480V

MATERIALS OF CONSTRUCTION

Body: Carbon steel ,Stainless Steel, Special materials
Knife:SS304,SS316(Solid solution treatment)
Stem :ANSI 1045+CR as standard,17-4PH for optional
Seat: EPDM as standard, NBR,PTFE
Connection:PN10

COMMON APPLICATIONS

• Waste Water and Water
• Pulp & Paper
• Food
• Fly Ash Handling
• Sewage
