Bi-directional knife gate valve

Bi-directional knife gate valve is made of cast iron and ductile iron . There is a groove which is installed the rubber in the bottom of body . The rubber is lined inner body .
The body is casted as a whole to easily exchange the seal ring and convinentily service .
Size:
2"26"
Material:
Cast Iron
Ductile Iron
Operation type :
Handle wheel
Pneumatic actuator
Electric Pneumatic actuator
Availability:
Inquire

PDF Export
facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
sharethis sharing button

  • BI-PZ73X

  • ZC

  • ZCBIPZ

Product Description

Product Specification

The body is casted  as a whole  to easily exchange the seal ring  and convinently service .

The sealing is depend on the bottom  of body , without design of groove seat , no  blocking , no residue , pipe cleaning is convenient 。

The surface  of gate is been grinded and polished  to  gain better sealing and protect the uselife of packing and seat effectly

Flange sealing is  installed  o ring ,  would not need to match flange  gasket ,simply installed ,reliable sealing

his product is widely used  the papermaking ,mine , metallurgy , chemical insustry  and water etc

No groove knife gate valve

Model:PZ73X 4”-24”

Solid One Piece Cast Body, Replacement seat,  rising stem,

Designed & Tested to MFS
Operated type: Pneumatic

MATERIALS OF CONSTRUCTION

Body:Carbon steel , Stainless steel and special material
Knife:SS304 as standard,,SS316 for option
Seat: EPDM ,NBR ,PTFE

COMMON APPLICATIONS

• Waste Water and Water
• Pulp & Paper
• Food
• Fly Ash Handling
• Sewage
